Features
Large, Full-colour Display
Features a 5-line colour display with a flexible menu-driven interface. Icons and large easy-to-use navigation buttons ease message reading and menu navigation.
Day/Night Mode on Display
This display has improved resolution for easier viewing even in broad daylight. It also also features a night mode that makes the screen easier to read in dark environments.
Best-in-class Audio
Loud front-facing speaker and Intelligent Audio feature that automatically adjusts the radio volume according to the environment’s noise level.
Text Messaging
Use text messaging when discretion is required or routine communication needs to be delivered without interrupting workers or guests.
Embedded Bluetooth Audio (option)
Embedded into the radio to enable connectivity with wireless accessories including Motorola’s unique Operations Critical Wireless earpieces designed for rugged and reliable communications
Embedded Bluetooth Data (option)
Share real-time information easily by connecting radios to Bluetooth-enabled data devices
Integrated GPS (option)
Locate mobile work teams using integrated GPS.
Emergency Button
Orange button on the top of the radio can be programmed to send an alert to a supervisor or dispatcher during an emergency situation.
Security
Three levels of scrambling or encryption built-in for increased security: 16-bit Basic Privacy, 40-bit Enhanced Privacy or 256-bit AES256 encryption
Transmit Interrupt
Enables a user to interrupt another radio conversation to deliver critical communication exactly when and where it’s needed.
IP Site Connect
A digital solution that uses the internet to extend the voice and data capabilities of MOTOTRBO. Use it to link up to 15 sites for communication among geographically dispersed locations, to create wide area coverage or enhance coverage at a single site with physical barriers.
Capacity Plus
Single-site digital trunking system that maximizes the capacity of your MOTOTRBO system. Use it to enable a high volume of voice and data communication for over a thousand users at a single site without adding new frequencies.
Linked Capacity Plus
Linked Capacity Plus is a multi-site digital trunking system configuration for the MOTOTRBO platform. It leverages the high capacity of Capacity Plus, with the wide area coverage capabilities of IP Site Connect to keep your staff at various locations connected with an affordable high capacity, wide area trunking solution.
Rugged, Reliable Design
Tightly sealed against wind and dust, and submersible in up to one meter of water for 30 minutes (IP57).
Productivity-enhancing Data Applications
Features the industry’s largest Application Developer Program to enable a wide variety of customized applications including: location tracking, email gateways, dispatch, telephony, man-down and work order ticket management
Intrinsic Safety
DP4000 Series radios are certified to meet the requirements for Factory Mutual (FM) and UL TIA4950 when properly equipped with a relevant Motorola battery option
Specification Sheet
MOTOTRBO DP4000 Series Data Sheet (EN)
MOTOTRBO™ DP4000 Series Digital Two-way Portable Radios Specification Sheet
MOTOTRBO DP4000 Series Data Sheet (ES)
MOTOTRBO™ DP4000 Series Digital Two-way Portable Radios Specification Sheet
MOTOTRBO DP4000 Series Data Sheet (IT)
MOTOTRBO™ DP4000 Series Portable Radios Specification Sheet
Performance Characteristics
-
Frequency band
VHF, UHF
-
4 5 Watt
Yes
-
Repeater capable
Yes
-
Battery life (based on a 05 05 90 duty cycle)
up to 23 hours in digital mode, 18 hours in analogue mode
-
1 Watt
Yes
Physical Characteristics
-
Available option board
Yes
-
Emergency button
Yes
-
Keypad
Full
-
Display
Full, Color, Day and night mode
-
Weight (with standard battery)
365.5 g (12.93 oz)
-
Dimensions H x W x D (with standard battery)
130.3 x 55.2 x 41.1 mm (5.13 x 2.17 x 1.62 inch)
Radio Features
-
Transmit interrupt
Yes
-
Digital private line
Yes
-
Private line
Yes
-
Monitor Permanent (Sticky) Monitor
Yes
-
Lone worker
Yes
-
Voice announcement
Yes
-
Signalling
DMR, PL/DPL, MDC, Quik-Call II, 5-tone, MPT1327 (option)
-
Intelligent audio
Yes
-
Bluetooth
Integrated Bluetooth audio, Integrated Bluetooth data
-
Programmable buttons
Yes
-
Voice operated transmit (VOX)
Yes
-
Time out timer
Yes
-
Talkaround
Yes
-
Text messaging capable
Yes
-
Scan types
Normal, Priority, Dual priority, Nuisance channel delete, Talk group, All group, System, Home revert
-
Group call
Yes
-
One to one calling
Yes
-
Missed call alerts
Yes
-
CPS (Customer Programming Software)
Yes
-
Channel spacing
6.25, 12.5, 25
-
Number of channels
1000
-
Channel scan
Yes
-
Caller ID
Yes
-
Call tones
Yes
-
Call forward
Yes
-
Busy channel lockout
Yes
-
Integrated voice and data
Yes
Technology
-
System type
Conventional, IP Site Connect, Capacity Plus, Linked Capacity Plus, Connect Plus
-
Digital technology
Yes
User Environment
-
Submersible
Yes
-
Intrinsically safe
Yes
-
Mil spec
810 C, 810 D, 810 E, 810 F, 810 G
-
Noise reduction software
Yes
-
IP Standards
IP57
Warranty
-
Standard warranty
2 years
