Features
Ultra-Slim
Measuring less than an inch thick, the SL1M redefines portability. It can be carried easily in a pocket or purse without catching or bulging.
Simple Operation
The SL1M features a separate power button, top channel toggle switch, side volume control buttons, and prominent push-to-talk button to support one-hand radio operation.
Dual Capacity Direct Mode
Utilize the power of the 2-slot TDMA DMR standard to double the capacity of your 12.5 kHz channel—without the need for a repeater.
IP54 Rated
Rugged and reliable, the SL1M is splashproof and dustproof for use in harsh environments.
Range Max Receiver
An advanced radio design and patented antenna which delivers enhanced range while maintaining a slim profile and long battery life.
Comprehensive accessory portfolio
Innovative carry options, earpieces and charging stations allow you to get maximum efficiency from your SL1M.
Active View Display
Shatterproof Active View display uses hidden LED lighting to communicate channel, radio, and volume information crisply in both daytime and nighttime situations.
Analog/Digital
Get all the benefits of digital, including better voice quality, better range and better battery life—but retain compatibility with your existing radio fleet. With analog and digital capability, you have the freedom to migrate to the latest technology at your own pace.
Transmit Interrupt Capability (Decode Only)
Radio could be interrupted to ensure critical communication could be delivered exactly when and where it’s needed.
Voice Announcement
Audible prompts confirm operations on your radio, allowing you to keep your eyes on the job.
MicroUSB Connectivity
Efficient charging and easy programming.
IP Site Connect
A digital solution that uses the internet to extend the voice and data capabilities of MOTOTRBO. Use it to link up to 15 sites for communication among geographically dispersed locations, to create wide area coverage or enhance coverage at a single site with physical barriers P Site Connect
Specification Sheet
MOTOTRBO SL1M Data Sheet
MOTOTRBO™ SL1M Portable Radio
Performance Characteristics
-
Standard battery chemistry type
Lithium Ion
-
Repeater capable
Yes
-
Power
1, 2, 3, Watt
-
Battery life (based on a 05 05 90 duty cycle)
Analog (hours) - 11.8 (VHF Display); 11.8 (UHF Display)Digital - 14 (VHF Digital);, 14 (UHF Display)
-
Frequency range
VHF - 136 - 174 MHz;
UHF - 403 - 470 MHz
-
Power
3.7V (Nominal)
-
Frequency band
VHF, UHF
Physical Characteristics
-
Display
Active View
-
Dimensions H x W x D (with standard battery)
4.95 X 2.17 x 0.87 in
(125.7 X 55.0 X 22.0 mm)
-
Weight (with standard battery)
VHF: 5.96 oz (168.9 g), UHF: 5.84 oz (165.6 g)
Radio Features
-
Voice announcement
Yes
-
Group call
Yes
-
Programmable buttons
Yes
-
Talkaround
Yes
-
Number of channels
256
-
Channel spacing (kHz)
6.25, 12.5
-
One to one calling
Yes
-
Missed call alerts
Yes
Technology
-
System type
Conventional, TDMA
User Environment
-
Mil spec
810 C, 810 D, 810 E, 810 F, 810 G
-
IP Standards
IP54
